Case mATX Chieftec BX-10B-OP, w/o PSU, 0.6mm, 1x120mm, USB-C, USB3.2, Tempered Glass, 3x2.5", 1x3.5"
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
.
Article no. BX-10B-OP
EAN code 0753263078063
Color Black
Material 0.6mm SPCC
Motherboard support Mini ITX, mATX
Dimension (DxWxH) 415mm x 204mm x 325mm + (15mm feet)
Weight (without/with package) 4.78 kg / 5.48 kg
Drive bay external -
Drive bay internal 1 x 3,5" & 3 x 2,5" or 4 x 2.5”
Power supply ATX PSU (optional)
Front I/O 1x USB3.2 Gen1 Type-A, 1x USB 3.2 Gen1 Type-C, Audio-Out/Mic-In
Scope of delivery Set of screws , 1x 120mm PWM fan pre-installed
Expansion slots 4
Cooling Compatibility Bottom: 3x 120mm or 2x 140mm (140mm only with ITX board)
Rear: 1x 120mm pre-installed
Top: 2x 120mm or 2x 140mm fans or 240mm radiator
CPU cooler height (max.) 165mm
VGA card length (max.) 380mm (300mm, if PSU longer than 180mm installed)
Audio Jacks
Headphone Out / Microphone In jack
Brand
Chieftec
Chassis Metal Thickness {mm}
0.6
Colour Category | Цветовая Категория
Black | Чёрный
Colour Name | Название Расцветки
Black | Чёрный
Cooling Fans Support
Front: 3x 120/ 2x 140mm, Rear: 1x 120mm, Top: 2x120/140mm
Dimensions, Depth {mm}
415
Dimensions, Height {mm}
325
Dimensions, Width {mm}
204
Drive Bays 2.5"
3
Drive Bays 3.5"
1
Fan Speed Controller
false
Gaming
false
Maximum CPU Cooler Height {mm}
165
Maximum VGA Card Length {mm}
380
Motherboard Form-Factor
Micro-ATX, Mini-ITX
Number of Expansion Slots
4
PC Case Type
Micro-ATX
PC Component Type
Case
Port Location
Front
Pre-installed Fans Rear
1x120mm
PSU Form-Factor
w/o PSU
Side Panel
Tempered glass
Sound Insulation Padding
false
USB 3.x Type-A
1x USB 3.2
USB Type-C
1x USB 3.2 Gen 1
Weight {kg}
7.05
