MB AM4 Gigabyte B450 GAMING X 1.0 ATX
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
// CPU AM4 Socket: AMD Ryzen™ 2nd Generation processors / AMD Ryzen™ with Radeon™ Vega Graphics processors / AMD Athlon™ with Radeon™ Vega Graphics processors / AMD Ryzen™ 1st Generation processors Chipset AMD B450 Memory 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory Dual channel memory architecture Support for DDR4 2933/2667/2400/2133 MHz memory modules Onboard Graphics Integrated Graphics Processor: 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz Maximum shared memory of 16 GB Audio Realtek® ALC892 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN Realtek® GbE LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x16 slot, running at x16 1 x PCI Express x16 slot, running at x4 2 x PCI Express x1 slots Multi-Graphics Technology Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies Storage Interface 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe 3.0 x4/x2 SSD support) 6 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10 USB - Chipset: 2 x USB 3.1 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) - Integrated in the APU: 4 x USB 3.1 Gen 1 ports on the back panel https://www.gigabyte.com/Motherboard/B450-Gaming-X-rev-10#kf
Addressable LED Header
2
Audio Jacks
HD Audio Jacks: Line in / Front Speaker / Microphone
Bluetooth Compliance
--
Brand
Gigabyte
COM Port
false
COM Port Header
Dimensions
30.2 x 23.5 cm
DisplayPort
--
DVI
1x DVI-I
Ethernet (LAN) controller #1
Gigabit Ethernet (Realtek RTL8118)
Ethernet (LAN) controller #2
--
HDMI
1x HDMI 2.0
LPT Port Header
M.2 Expansion Slots
1
Max. Memory Speed (OC) {Mhz}
3600
Memory Speed
2133 MHz
Motherboard Form-Factor
ATX
PC Component Type
Mainboard
PCI Slots
PCI-Express x1 Slots
2
PCI-Express x16 Slots
1
PCI-Express x4 Slots
PCIe 4.0 Support
false
RAID
RAID 0, RAID 1, RAID 10
RGB LED Headers
1
SATA Ports
6x SATA 6Gb/s
Slot support M2 #1
M2: SATA3 & PCIe Gen3 x4 (32 Gb/s)
Slot support M2 #2
--
Slot support M2 #3
--
Slot support M2 #4
--
SPDIF Out
1x Optical SPDIF Out Port
Thunderbolt
--
Total RAM Maximum Size
128GB
USB 2.0 Headers
1x USB 2.0 (Support 2 USB Ports)
USB 2.0 Type-A
4x
USB 3.x Headers
1 x USB 3.2 Gen1 (Supports 2 USB 3.2 Gen1 ports)
USB 3.x Type-A
4x USB 3.1
USB Type-C
--
Wi-Fi Controller
--
