// Essentials
Intel® NUC Kit with 10th Generation Intel® Core™ Processors
Board Form Factor
UCFF (4" x 4")
Internal Drive Form Factor
M.2
DC Input Voltage Supported
19 VDC
Processor Included
Intel® Core™ i3-10110U Processor (4M Cache, 2.10- 4.10 GHz)
# of Cores / of Threads
2 /4
Memory & Storage
Max Memory Size (dependent on memory type): 64 GB
Memory Types
DDR4-2666 1.2V SO-DIMM
Max # of DIMMs: 2
Processor Graphics
Processor Graphics ‡ Intel® UHD Graphics
Graphics Output
HDMI 2.0a; USB-C (DP1.2)
# of Displays Supported ‡ 3
Expansion Options
PCI Express Revision Gen3
M.2 slot with PCIe X4 lanes
Removable Memory Card Slot
SDXC with UHS-II support
I/O Specifications
# of USB Ports : 7
USB Configuration
2x front (Type-A, Type-C) and 3x rear USB 3.1 Gen2 (2x Type-A, Type-C); 2x USB 2.0 via internal headers
Max # of SATA 6.0 Gb/s Ports: 2
Audio (back channel + front channel)
7.1 digital (HDMI mDP); L+R mic (F)
Integrated LAN
Intel® Ethernet Connection I219-V
Integrated Wireless‡
Intel® Wi-Fi 6 AX201
Integrated Bluetooth: Yes
Consumer Infrared Rx Sensor: Yes
# of Thunderbolt™ 3 Ports: 1
Chassis Dimensions
117 x 112 x 38mm
