Pedal Body Material Aerospace-grade aluminum alloy
Heel Plate Material 3K twill cartoon fiber
Base Material High-strength steel
Load Cell Sensor Range 0-200kg
Brake Sensor Load cell sensor and angle sensor
Angle Sensor Resolution 15-blt (32768 PPR)
Brake Pedal Feel 115 standard adjustments, 1764 optional configurations
Throttle Adjustment two spring options with infinite adjustment
Clutch Adjustment two spring options with infinite adjustment
Brake Travel Adjustment 15-20°
Throttle Travel Adjustment 15-23°
Clutch Travel Adjustment 15-25°
Pedal Angle Adjustment 0-15°
Pedal Face Height Adjustment upto 30mm
Footrest Adjustment upto 30mm
Pedal Curve Adjustment Adjustable
Real-time Pedal Output Display Adjustable
Pedal Pressure Engagement Point Adjustable
Pedal Surface Biomimetic curved
Inverted Mounting IGt Optional
